We have developed and sold this Rotation Reducer for Crawling Crane to European, American and Southeast Asian market for many years. We have a professional product design and manufacture team to guarantee the quality and delivery time for customers. Welcome to buy Rotation Reducer for Crawling Crane from us. Every request from customers is being replied within 24 hours.
1.Product Introduction of Rotation Reducer for Crawling Crane
We have manufactured this Rotation Reducer for Crawling Crane since 2006. We have a plenty of experience and advanced equipment in manufacturing Rotation Reducer for Crawling Crane with the precisely helical teeth and balanced sun-gear shaft. This Rotation Reducer for Crawling Crane can transfer power from hydraulic motor to winch or rotatory machine.
2.Product Parameter (Specification) of Rotation Reducer for Crawling Crane
|
Output torque（TmaxN.m） |
Transmission ratio |
Model of hydraulic motor |
Static brake torque(TBRmax.N.m) |
|
28500 |
67.9 73.5 80.4 89.2 101 117.6 |
A2FE45 A2FE56 A2FE63 A2FE80 A2FE90 |
450-800 |
3.Product Feature And Application
This Rotation Reducer for Crawling Crane includes several planetary gear set which is made up of the sun gear (center gear), several planet gears and ring gear which rotate between each others. The load from the sun gear is distributed to multiple planetary gears which can either be applied to actuate an outer ring or a shaft or spindle. The center sun gear of Rotation Reducer for Crawling Crane can change a high speed and low torque input from hydraulic motors or electric motors to a low speed and high torque output. This Rotation Reducer for Crawling Crane is widely applied in wheel drives, slew drives, winch drives, track drives and cutter heads.
4.Product Details of Rotation Reducer for Crawling Crane
Our Rotation Reducer for Crawling Crane has a simple design which can transfer power from a motor to an output in high efficiency. Approximately 97% of the energy input is delivered as an output due to our advanced processing equipment and unique design. Our Rotation Reducer for Crawling Crane boasts low and high speed functions and unbeatable long-life performance, ideal for winches and mobile equipment.
5.Product Qualification of Rotation Reducer for Crawling Crane
Our products are certificated by CCS, DNV, BV, LR. Each product is delivered with a quality certification.
6.Deliver,Shipping And Serving of Rotation Reducer for Crawling Crane
We can guarantee to provide a short delivery time and high performance products to our customers. We also provide one year warranty.
